Pigtronix EP-1

Pigtronix EP-1

PhaserAnalog
List price
$220
Key facts
TypeAnalog envelope phaser pedal with a univibe-style rotary phaser mode1
MakerPigtronix
Power12vAC, US 120vAC supply included1
Extra I/OEF trigger side-chain input; expression pedal input1

The Pigtronix EP-1 Envelope Phaser is an analog phaser pedal that reacts to how hard you play. Pigtronix describes it as an "incredibly fat and vocal, touch sensitive envelope phaser" paired with a "deep and chewy, univibe style rotary" phaser mode, so one box covers two flavors of modulation: envelope-driven phase shifting and a fixed rotary-speaker style sweep1.

The pedal was aimed at a wide range of players. Pigtronix billed it as "Ridiculously FAT, Funky Tone for Guitar, Bass, Keys, Turntables, Laptops and Studios," which puts bass players squarely in its intended audience1.

What it does and how it works

The envelope phaser section is touch sensitive: the phase sweep follows the dynamics of your picking, opening up as you play harder. The second mode is a rotary phaser in the univibe tradition, a slower, continuous sweep rather than an envelope-driven one1.

Two features set the EP-1 apart from a basic phaser:

  • Footswitchable phase inversion, which flips the phase relationship of the effect, a useful trick for stereo rigs or for combining it with other effects1.
  • Expression pedal speed control for the rotary mode, letting you sweep the rotary speed with your foot for what the maker calls "mind bending rotary speaker effects"1.

The EF trigger input

The EF trigger is a side-chain input. It allows an instrument's sound to be phase modulated by an external audio source, such as a drum machine or a laptop, so the phasing can follow an outside rhythm instead of your own attack1. This is the feature that made the EP-1 interesting to players beyond guitar and bass, including DJs and laptop performers.

Power

The EP-1 does not run on a battery or a standard pedalboard supply: it uses an included US 120vAC power supply1.

The EP-1's AC power requirement means it cannot run on a battery or a daisy chain. A US 120vAC supply was included with the pedal, and a Euro or UK supply could be supplied for $201.

Where it came from

Pigtronix describes the EP-1 Envelope Phaser as delivering "Ridiculously FAT, Funky Tone for Guitar, Bass, Keys, Turntables, Laptops and Studios."1

Videos

Pigtronix EP-1 Envelope Phaser Pedal
ProGuitarShopDemos
Pigtronix EP-1 Envelope Phaser Demo Video Ernie Jackson
Pigtronix
Pigtronix Envelope Phasers - EP1 vs. EP2
TheGuacamoleXplosion

Questions

Can the Pigtronix EP-1 be used on bass?

Yes. Pigtronix describes the EP-1 as delivering fat, funky tone for guitar, bass, keys, turntables, laptops and studios, so bass is explicitly among the instruments it was built for. Pigtronix later released a dedicated Bass Envelope Phaser as well.

What is the difference between the Pigtronix EP-1 and EP2?

The EP2 is a rework of the EP1. Pigtronix announced the redesigned EP2 Envelope Phaser in June 2010, six years after the original EP-1 arrived. No Treble's review of the EP2 praised its sound and its Staccato switch while criticizing its small switches.

Does the Pigtronix EP-1 run on a 9V adapter?

No. The EP-1 uses a 12vAC power supply, and a US 120vAC supply was included with it. That rules out the standard 9V DC center-negative pedal adapter most players use, so it needs its own supply.

What does the EF trigger input on the EP-1 do?

The EF trigger is a side-chain input. It lets an external audio source, such as a drum machine or laptop, drive the phase modulation of your instrument's sound, so the phasing follows an outside beat rather than your own attack.

Sources (1)
  1. PIGTRONIX EP-, Analog Man (analogman.com), 2015
