Pigtronix PolySaturator

Pigtronix PolySaturator

Distortion
List price
$209
Key facts
TypeMulti-stage analog distortion pedal1
MakerPigtronix1
BypassTrue bypass1
Power15V DC adapter, included1
I/OInput and output jacks both on the right side of the unit1
CircuitFour vintage JRC4558D chips, Class A J-FET booster stage1

The Pigtronix PolySaturator is a multi-stage analog distortion pedal from Pigtronix, built around vintage JRC4558D op-amp chips and carrying a wide gain control plus an adjustable three-band active EQ. Premier Guitar reviewed it as a pedal that trades a wall of saturated distortion for gritty, old-school, organic rock tones with unusually strong low end1.

Controls and EQ

The PolySaturator's gain control is described as wide, giving it a broad range of drive settings. The active EQ provides 12dB of cut or boost at three fixed frequencies: 180Hz, 420Hz and 1KHz1. The JRC4558D-powered EQ circuits provide what the maker describes as 12 dB/octave active filtering over three distinct audio bands2.

ControlWhat it does
GainWide-ranging drive control1
Low12dB cut or boost at 180Hz1
Mid12dB cut or boost at 420Hz1
High12dB cut or boost at 1KHz1

Circuit and chips

Inside, the pedal takes its overdrive concept further by adding four vintage JRC4558D chips, a Class A J-FET booster stage and a secret "special little chip" at the front end1. The JRC4558D is the op-amp most associated with classic overdrive circuits, and here it also powers the EQ filtering2. The circuit design is credited to Howard Davis2.

Relation to the Disnortion

The PolySaturator's three-band active EQ uses JRC4558D op-amps, providing 12 dB of cut or boost at 180 Hz, 420 Hz and 1 kHz21. Where the Disnortion line pairs distortion with other effects in one box, the PolySaturator focuses on multi-stage distortion with that EQ on top.

Power, size and connections

The PolySaturator comes with a 15V DC adapter1. Both the input and output jacks sit on the right side of the unit, an unusual arrangement that affects where the pedal can sit on a board1. It is smaller than a Boss pedal and fit the reviewer's pedalboard without trouble1.

The PolySaturator runs on 15V DC rather than a common pedal supply voltage. The adapter is included with the pedal1.

What reviewers said

Premier Guitar's reviewer found the pedal produced gritty, old-school, organic rock tones with freakish low end rather than a wall of saturated distortion1.

"I was particularly impressed with its articulation and definition. Even with the gain maxed, I could hear the clarity beneath its monstrous growl."
Premier Guitar review, 20211

First edition and availability

The first edition of the pedals was hand-painted by Jason Myrold, of Zvex fame1. Players looking for one may need to search the used market2.

Videos

Pigtronix Polysaturator Distortion Pedal
ProGuitarShopDemos
Pigtronix Polysaturator Distortion
ProGuitarShopDemos
Joe Bonamassa at Pigtronix LA Amp Show '09 - PolySaturator
Pigtronix

Questions

Is the Pigtronix PolySaturator true bypass?

Yes. Premier Guitar's review confirms the PolySaturator is true bypass, so with the pedal off your signal passes through without buffering or coloration. It runs on a 15V DC adapter, which is included with the pedal1.

What chips are in the Pigtronix PolySaturator?

The circuit uses four vintage JRC4558D op-amp chips, plus a Class A J-FET booster stage and what the maker calls a secret "special little chip" at the front end. The JRC4558D chips also power the EQ circuits12.

How is the PolySaturator related to the Disnortion?

The Pigtronix catalog states the PolySaturator is based on the overdrive tones found in their Disnortion pedal, taken further with the added chips and booster stage1.

Who designed the Pigtronix PolySaturator?

The circuit design is credited to Howard Davis, and the first edition was hand-painted by Jason Myrold, of Zvex fame12.
