The Xvive V15 Tone Shaper Equalizer is a two-band EQ micro pedal made by Xvive. It gives the player three controls, one for lows, one for highs and one for overall level, in an analog circuit with true bypass switching1. It is aimed at players who want to shape their tone without a large graphic EQ taking up board space, and its micro-pedal size is part of the point: the whole unit measures 94 x 46 x 50 mm and weighs 250 g1.
The circuit is described as a 2-band equalizer with multi-pole sharp cut-off filters, meaning the low and high bands are cut with steeper filter slopes than a simple single-pole design, so the bands stay more separate from each other as you boost or cut them1. The pedal is also listed with low distortion and a round tonal character, and with up to 6 dB of gain available12.
What it does and how it is controlled
The V15 is a straightforward tone-shaping tool rather than an effect that adds anything dramatic. The three knobs cover the two EQ bands and the output1:
| Control | What it does |
|---|---|
| Lows | Cuts or boosts the low-frequency band |
| Highs | Cuts or boosts the high-frequency band |
| Level | Sets the overall output level |
A single bypass footswitch turns the EQ on and off, and because the pedal is true bypass, the signal passes straight through when it is off1. The housing is metal, and the jacks are standard 6.3 mm mono, so it drops into any normal signal chain1.
For a bass player, a two-band EQ of this kind is the same basic arrangement found on many bass amplifiers: roll off some highs to calm a bright rig, add lows for weight, or cut lows to tighten things up. The multi-pole sharp cut-off filters mean the two bands interfere with each other less than they would on a cruder circuit1. One listing also describes the pedal as having excellent dynamic response, so the playing dynamics come through the EQ section without being squashed2.
Power and setup
The V15 runs on a 9V DC power adapter with a 2.1mm x 5.5mm barrel connector and center negative polarity, drawing 15 mA12.
Battery operation is not supported, so the V15 needs a 9V DC supply. The adapter is not included with the pedal1.
At 15 mA the draw is low enough that the pedal is easy to power from a shared or isolated supply alongside other micro pedals, such as others in the Xvive line like the Xvive B1 Bass Squeezer or the Xvive V13 Mini DI1.
Size and build
The V15 is built as a micro pedal: 94 mm long, 46 mm wide and 50 mm high, about 3.7 by 1.8 by 2.0 inches, and 250 g in weight12. Both listings agree on the dimensions. The enclosure is metal, and the whole package is sold as a micro pedal12. That footprint is small enough to slot into gaps on a pedalboard where a full-size graphic EQ would not fit.
Compared with a preamp-style EQ
The V15 is a pure EQ rather than a preamp. A useful comparison is the Xotic BB Preamp, a bass preamp pedal that includes an adjustable ±15dB two-band active EQ alongside its gain stage, with true bypass switching324. The Xotic approach bundles tone shaping with overdrive-style gain in a full-size enclosure, while the V15 keeps only the EQ job and shrinks it into a micro box. A player who wants EQ plus drive in one unit is looking at the preamp route; a player who just wants to cut or boost lows and highs around an existing rig can do it with the V15 and a fraction of the board space.
Questions
Does the Xvive V15 take a battery?
No. The V15 runs on a 9V DC power adapter only, through a 2.1mm x 5.5mm barrel connector with center negative polarity. Battery operation is not supported, so it needs a spot on a power supply or an isolated adapter rather than a battery.
Is the Xvive V15 true bypass?
Yes. The V15 uses a true bypass design, so when it is switched off the signal passes through without the pedal's circuitry in the path. This is the switching arrangement listed for it by retailers carrying the pedal.
How big is the Xvive Tone Shaper V15?
The V15 measures 94 x 46 x 50 mm (length by width by height), about 3.7 inches deep and 1.8 inches wide, and weighs 250 g. That micro-pedal footprint makes it easy to fit on a crowded pedalboard.
