EarthQuaker Devices Erupter

EarthQuaker Devices Erupter

FuzzAnalogDiscontinued
List price
$149
Key facts
TypeOne-knob fuzz pedal, all-analog signal path12
MakerEarthQuaker Devices, built by hand in Akron, Ohio2
ReleasedMay 10, 20172
StatusNo longer in production1
BypassTrue bypass with electronic relay-based switching; audio will not pass without power1
Power9V battery or standard 9V DC supply, 2.1mm negative center barrel, 9 mA current draw1
Dimensions4.75 x 2.50 x 2.25 in. (121 x 64 x 57 mm) with knobs1
Input / output impedance500 kΩ input, <1 kΩ output1

The EarthQuaker Devices Erupter is a one-knob fuzz pedal built by EarthQuaker Devices in Akron, Ohio. Released on May 10, 2017, it takes a classic fuzz circuit, fixes the gain at maximum, and gives you a single knob that biases the circuit instead of setting volume or fuzz level12. EarthQuaker describes the result as the ultimate classic fuzz tone, with a big low end, a biting top end without being too harsh, and just enough output to push a tube amp over the top1.

The pedal is no longer in production: EarthQuaker lists it as discontinued, and it appears on the company's Legacy page of retired products13. It carried a lifetime warranty while it was made1.

What the Erupter is and where it came from

The Erupter is built on a classic fuzz topology with a low parts count, a circuit family EarthQuaker notes has many variations on the market whose sound always varies1. In an interview with JHS Pedals, EarthQuaker founder and president Jamie Stillman described it in more specific terms:

"essentially it's a super elaborate version of a fuzz face with a transformer pick up simulation in it"
Jamie Stillman, JHS Pedals interview6

Stillman, EarthQuaker's president and product designer, said the pedal is totally inspired by the Fuzz Face, one of his all-time favorite fuzz pedals7. The design rationale behind removing the knobs is blunt: Stillman says players turn both Fuzz Face knobs all the way up anyway, and that the pedal sounds better in general without them6. The transistors are NOS, hand-matched, low-gain silicon, chosen for temperature stability and predictable operation under all extremes1. Each Erupter was built by hand in Akron, Ohio2.

The Bias control and its center detent

The Erupter's only knob is Bias, and it does not do what a fuzz knob usually does. As Premier Guitar's reviewer put it58:

"Erupter's single knob doesn't control volume or gain. Instead, it controls bias, or the flow of voltage to the circuit."
Premier Guitar5

The gain or fuzz level is effectively the same as a gain knob set to maximum, no matter where Bias sits5. What the knob changes is the character of the fuzz:

Bias positionWhat happens
Center detentThe "perfect" fuzz setting: big, round tone with a slight volume boost and great sustain1
Counterclockwise of centerMore gated, with lower output1
Clockwise of centerLouder and more refined1

EarthQuaker had a custom center-detent pot made to fit the required resistance for the pedal, so the sweet spot is physically marked1. Premier Guitar's reviewer found that the noon position, marked by the potentiometer detent, showcases the pedal's harmonic balance, and that backing off the guitar volume turns the tone from fuzz toward distortion5.

MusicRadar's reviewer Rod Brakes characterized the Bias control as more of the "sounds usable everywhere" kind of bias, dialled cooler or hotter around the center detent8. Premier Guitar found the lowest bias settings sound amazing at their spittiest and nastiest, especially with bridge single-coils; neck single-coils smooth the output while retaining the gated splat, and humbuckers are an even better fit5. In the 9 to 11 o'clock range, the reviewer found a fuller, more harmonically rich foundation that retains the random and fractured qualities of the more voltage-starved settings, with clear note-to-note fundamentals beneath the fuzz on chords, and volume attenuation yielding rich, growling overdrive sounds5. Past noon, the tones become explosive but slightly less appealing to that reviewer's ear, though most effective when a stage mix is dense and a solo has to get out over the din5.

Volume, output level, and bypass

There is no volume knob. Premier Guitar's reviewer found the volume is fixed somewhere just north of really loud, which means using your guitar volume to control your overall output5. The buffered front end is part of how the pedal handles level and tone: EarthQuaker says it gives the best possible input signal, with stronger highs and tighter lows1. Stillman told JHS that the pedal is buffered and that this gives it a little more clarity6.

The switching is true bypass with electronic relay-based switching, and audio will not pass without power1.

Because the Erupter uses relay-based switching, it needs power to pass signal even in bypass. If it drops off your board's power supply, your signal stops. It runs on a 9V battery or a standard 9V DC supply with a 2.1mm negative center barrel, drawing only 9 mA1.

What reviewers said

MusicRadar's Rod Brakes found the Erupter offers strong definition and clarity, and that it cuts through a band mix easily, where Fuzz Faces are sometimes difficult in that situation, without harsh highs and with distinction and clarity at the low end even on full tilt8. Gearnews noted its handily small size and its ability to run from either a battery or an external 9V power supply as appealing points9. At launch, MusicRadar reported a UK price of £15510, and Premier Guitar listed a US street price of $1455; JHS Pedals later cited $1494.

Videos

Earthquaker Devices Erupter
ProGuitarShopDemos
Earthquaker Devices Erupter Fuzz with Mike Hermans
ProGuitarShopDemos
EarthQuaker Devices Erupter Fuzz Pedal Review
Sweetwater

Questions

Does the Erupter have a volume knob?

No. The Erupter's single knob is a Bias control, not a volume or gain control. It sets the flow of voltage to the circuit. Volume is fixed at the factory at a loud setting, so you control your overall output level with your guitar's volume knob.

How do you control the Erupter's output level?

With your guitar's volume knob. The pedal's output is fixed somewhere just north of really loud, and the gain or fuzz level is effectively the same as a gain knob set to maximum. Backing off the guitar volume also moves the tone from fuzz toward distortion.

Is the Erupter true bypass or buffered?

Both, in a way. The bypass is true bypass with electronic relay-based switching, and audio will not pass without power. The front end is buffered, which EarthQuaker says gives the best possible input signal with stronger highs and tighter lows.

Is the EarthQuaker Erupter discontinued?

Yes. EarthQuaker Devices states that the Erupter is no longer in production, and it appears on the company's Legacy page of discontinued products. It was released on May 10, 2017, and carried a lifetime warranty while it was in production.
